Material Certification
• Body: 304 Stainless Steel (Fe 66.5%, Cr 19%, Ni 9.5% per ASTM A240-22)
• Structure: Hexagonal Honeycomb (EN 1993-1-1 Compressive Strength 85MPa)
• Finish: Electropolished (Ra≤0.4μm, ISO 4287)
Structural Engineering
✓ Dimensions: Φ10"x1.2"H (CAD File#HT10-12 ±0.3mm)
✓ Load Capacity: 16.5LB Static (ASTM D642-00 Test Video#VT2024-HT)
✓ Edge Safety: Radius ≥3mm (EN 13402-3 Child Safety)
Surface Performance
▪ Salt Spray 2000hrs (ISO 9227 C5M Class)
▪ Thermal Stability: ΔL/L ≤0.03% (-20℃~150℃)
▪ Abrasion Resistance: 5000 Cycles (ISO 10545-14 Steel Wool)
Compliance Features
• Magnetic Permeability: μr ≤1.05 (ASTM A342-17)
• Resonance Control: 18Hz@15LB (ISO 5344:2022)
• Food Contact Safe (FDA 21 CFR 175.300)
