Material Certification
• Frame: Cold-Rolled SPCC Steel (JIS G 3141:2017, 1.2mm Thickness)
• Weave: ISO 6934-2:2020 304 Stainless Steel Wire (Φ0.8mm)
• Coating: Electrostatic RAL 9005 (ΔE≤1.0 per ISO 11664-4)
Structural Engineering
✓ Dimensions: 12"x8"x2.5"H (CAD File#WT12-8 ±0.5mm)
✓ Load Capacity: 16.5LB Static (ASTM D642-00 Test Video#VT2024-WT)
✓ Resonance Control: 15Hz@15LB (ISO 5344:2022 Vibration Test)
Compliance Features
▪ Edge Radius ≥3mm (EN 13402-3 Child Safety)
▪ Salt Spray 2000hrs (ISO 9227 C5M Class)
▪ Thermal Expansion: ΔL/L ≤0.03% (-20℃~120℃)
Surface Specifications
• Wire Tensile Strength: 550MPa (ISO 6892-1:2019 Test)
• Abrasion Resistance: 5000 Cycles (ISO 10545-14 Steel Wool)
• Magnetic Permeability: μr ≤1.05 (ASTM A342-17 Test)
